B25 Brewing System

The B25 is designed to be the ultimate brewing system for kitchens, apartments, and other space-conscious environments. It combines exceptional simplicity and ease of use with the same powerful technology found in its larger siblings.

Indirect heating and the integrated cooling jacket make cleaning quick and effortless, while the 8" touchscreen can be mounted directly on the system or remotely to suit your workspace (optional longer cables available).

Wort flow through the FCS Brew Pump is precisely controlled via the patented CleanCore sanitary 3-way valve, conveniently operated from the front of the system. An integrated temperature and liquid level sensor continuously monitors the system and automatically disables both the pump and heating elements if the liquid level becomes too low, ensuring safe operation.

All in all, the B25 is built to be insanely durable and easy to use.

• Indirect heating (flat bottom)
• Integrated cooling jacket
• Powered by FCS Brewing with an 8" Touch Screen
• Patented CleanCore sanitary 3-way valve

• Remember to get power cables for your area (purchased separately)
  The B25 needs 1 LP20 power cable (Schuko, UK BS1363 etc.)



  Available controller ports:

  - 1 CAN bus ports (+24V)
  - 1 external high level switch (not used on the B25 as of now)

  - 1 mash temp sensor input (sold separately)



  In the box:

  - B25 brewing system with malt pipe and lid

  - Malt Pipe with laser cut filter

  - Malt pipe draining holder

  - Silicone tubing for draining and recirculation

  - Parts and accessories for assembly



  Specifications:
  Batch size: 5-20 liters

  Total volume capacity: 28 liters

  Grain capacity: 4.8 kg

  Heating power: 2000W (230V) | 1500W (120V)

  Watt density: 4.18W/cm2 | 3.14W/cm2

  Control system: FCS Brewing with 8" IPS touch screen

  Connectivity: Wi-Fi 2.4 GHz 802.11ax/b/g/n

  Pump: Brewtools FCS Brew Pump, 30 l/min, 4.5m head

  Materials: 304 Stainless steel, food grade silicone, EPDM, POK (Polyketone)

  Valves, fittings, and connections: TC34mm

  System height: 635mm

  Tank dimensions : Ø300mm, height 400mm (28.27 liters)

  Malt pipe dimensions: Ø225mm, height 345mm (13.72 liters)

  Packing dimmensions and weight: 440 x 440 x 700 mm / XX kg (TBD)
  Safety features: Overheat protection, dry-boil protection, liquid detection

  Warranty: 5 years



  Remember:

  - Power cable(s)

  - Connectors for cooling jacket (kit or custom setup)

  - Tubing for cooling setup
